The composite ultraviolet test chamber manufactured by Wuxi Baishiqi Photovoltaic Technology Co., Ltd. is a comprehensive environmental simulation equipment that combines high and low temperature testing and ultraviolet aging testing. It n...
TEL
15861558832
■ The composite ultraviolet test chamber manufactured by Wuxi Baishiqi Photovoltaic Technology Co., Ltd. is a comprehensive environmental simulation equipment that combines high and low temperature testing and ultraviolet aging testing.
■ It not only has the basic functions of a high and low temperature test chamber, but also simulates sunlight exposure through ultraviolet lamps to test the durability and aging of materials under extreme temperatures and ultraviolet radiation.
The composite ultraviolet test chamber can simulate extreme high and low temperature environments, and has high temperature control accuracy. It can conduct tests within a small range of temperature and humidity fluctuations, ensuring the accuracy and repeatability of test results.
Equipped with an intuitive and easy-to-use touch screen or computer control system, users can easily set test parameters, monitor the testing process, and obtain detailed test reports. The operation is convenient and the information is clear at a glance.
Built in multiple safety protection devices, such as over temperature protection, leakage protection, overload protection, etc., ensure the safety and reliability of the testing process, effectively avoiding the occurrence of accidents.
Adopting high-efficiency insulation materials and energy-saving refrigeration/heating systems to reduce energy consumption and meet the requirements of modern enterprises for green production.
The high and low temperature ultraviolet test chamber is widely used in various fields. By precisely controlling the temperature changes inside the chamber, the performance of the product is tested under extreme conditions to evaluate its stability, durability, and reliability in different environments.
| Light source drive | EPS（50%--100%Continuing Adjust） | Distance from component to lamp | 1400mm |
| Irradiance area | Personalized customization | temperature range | -50～130℃ |
| Number of light sources | Personalized customization | Temperature deviation | ≤±2℃ |
| Single lamp power | 2kW | temperature fluctuation | 0.5℃ |
| Lamp lifespan hours | ＞2500 hours | Temperature uniformity | ≤2℃ |
| Lamp warranty hours | 2000小时 | heating rate | Linear 2 ℃/min with load linear electrification @ (-40~85 ℃) |
| Light intensity range | 150～250W/m2 | cooling rate | Linear 2 ℃/min with load linear electrification @ (85-40 ℃) |
| spectral range | 280～320nm 320～400nm | Humidity range | 20～98%RH |
| UVB/(UVA+UVB) | 3～ 10% | humidity uniformity | ≤±2%RH |
| Brand of irradiance sensor | Obodi | Humidity deviation | ≤±2%RH |
| Non-uniformity of irradiation | ≤10% | Humidity fluctuation | ≤±1.5%RH |
| UVC content | The ratio of integrated irradiance within the wavelength range of (250-280) nm to integrated irradiance within the wavelength range of (250-400) nm is ≤ 0.3% | Temperature and humidity monitoring | Provide one T-shaped thermocouple for temperature monitoring for each sample. Humidity sensor brand: E+E |
|
|
|
||
|
Accumulated sales quantity>50 sets
|
||||
